Wireless Lora Water Meter Without Valve Control

JYME1S004-LXSZ-ZL Series Wireless Direct Water Meter is a valve-free intelligent remote water meter based on Lora standard communication protocol.

Send Inquiry

Product Description

JYME1S004-LXSZ-ZL Series Wireless Direct Water Meter is a valve-free intelligent remote water meter based on Lora standard communication protocol. With LORA wireless technology, communication distance is far, convenient for networking. Easy to write reading and controlling water meters, realizing remote direct reading of water meters, effectively avoiding the management department on top table reading, and improving meter reading efficiency.

The water meter is designed with an electromechanical separation structure, and the measurement is accurate. The base table and the wireless electronic unit can be completely separated, and their own independent operation is convenient to install, which is convenient for later maintenance.

Model:

JYME1S004-LXSZ-ZL MA103C

Brand:

JinYuming

Items	Unit	Parameters
		DN15	DN20	DN25
Diameter	mm	15	20	25
Q₃(m³/h)	(m³/h)	2.5	4.0	6.3
R(Q3/Q1)	(m³/h)	160 125 100 80
Permissible Error	Q₂ ≤Q≤Q₄	2%
	Qi≤Q<Q2	5%
Working Temperature	℃	0.1℃~ 50℃
Max. Working Pressure	MPa	1.6MPa
Pressure Loss	MPa	≤0.063MPa
Max. Reading of the Counter	m³	99999
Pulse Equivalent	m³	0.001

Table 2 JYME1S004-LXSZ- ZL Series Electrical Parameters

	Name	Parameters				Remark
	Name	Minimum	Typical	Maximum	Unit	Remark
1	Quiescent operating current		16		uA
1	Dynamic operating current			120	uA	Multimeter peak value
2	Battery undervoltage alarm point	3.1		3.3	V
3	Wireless Communication Current		30	150	mA
4	Continuous Working Time	7			year	Related to the number of meter readings
5	Communication distance			1	km	In an open environment, the water meter is above the ground.
6	Main Power	+2.7	+3.6	+3.9	V
7	Minimum communication voltage	2.7			V	The voltage value measured when the battery is activated
8	Operating temperature	-10		50	℃
9	Storage Temperature	-20		60	℃
10	Humidity		85%
11	Wireless communication baud rate			9600	Bps
12	Frequency	470	475	480	MHZ	470MHZ, 868MHZ, 915MHZ
13	Channel		21		piece

Table 3 JYME1S004-LXSZ-ZL Series Power Consumption

	Current consumption details	Current parameters		Each Duration		Each Time Interval	Annual Power Consumption (AH)
	Current consumption details	Size	Unit	Each Duration		Each Time Interval	Annual Power Consumption (AH)
1	Motherboard quiescent operating current	20	uA				0.2
2	LORAWAN module sleep current	20	uA				0.2
3	LORAWAN data reporting current note	120	mA	100	mS/time		0.03~0.12
4	MCU wake-up power consumption	300	uA	1	mS/time	172,800 times per day	0.0053
5	Battery self-depletion						0.1
6	Total						0.535~0.625
